Synthesis Dual 5.25IN Angled in-Wall Compression Driver Speaker

Se importa de EE. UU. bajo pedido. El precio ya incluye la importación y el IVA; la entrega en México se cotiza con tu pedido.

Características (del fabricante, en inglés)

• 2-way in-wall loudspeaker system designed for off-axis listening as LCR and surround channels
• 1-inch 2410H-2 compression driver tweeter mated to a JBL patented High-Definition Imaging (HDI™) horn precision molded baffle assembly
• Two 5.25-inch (130mm) Advanced Aluminum Matrix cone cast frame woofers
• Can be mounted vertically or horizontally
• Patented Cat Claw installation mechanism
• Gold plated, spring-loaded binding posts
• Includes paintable zero-bezel, magnetically attached grilles

Medidas y especificaciones (en inglés)

• Recommended Amplifier Power 25 – 150W RMS
• Impedance 4 Ohm
• Loudspeaker Sensitivity 88 dB/2.83V/1m (2pi anechoic)
• Frequency Response 55Hz - 30kHz (-6 dB on-axis), 2pi anechoic
• Crossover Frequency 2.0 kHz
• High Frequency Coverage Angle (-6 dB) 60° Vertical, 90° Horizontal (Left 30°, Right 60°, from center line), from 2 kHz to 15 kHz
• Grille Dimensions 7.32” (186 mm) x 19.15” (486 mm)
• Product Dimensions (with grille) 7.32” (186 mm) x 19.15” (486 mm) x 3.88” (99 mm)
• Cut-out Dimensions 6.18” (157 mm) x 18.03” (458 mm)
• Rough-in Bracket WB52
• Mounting Depth 3.64” (93 mm)
• Product Weight 12.6 lbs (5.72 kg)
• Shipping Weight 14.6 lbs (6.62 kg)
• Warranty 5 Years

Descripción del fabricante (en inglés)

2-Way Dual 5.25-inch (130mm) In-Wall Loudspeaker The SCL-7 is the smallest in-wall model in the expanded JBL Synthesis Custom Loudspeaker (SCL) series. It is designed for deployment in high-performance immersive audio systems in small to medium size rooms. The SCL-7 features JBL’s patented 2410H-2 1-inch (25mm) compression driver mated to an offset High Definition Imaging (HDI™) horn. The innovative configuration yields incredibly smooth and consistent performance for off-axis placement up to 45 degrees from the listening position.
