Single Port Long Range Ethernet Over Coax Extender (2X)

Se importa de EE. UU. bajo pedido. El precio ya incluye la importación y el IVA; la entrega en México se cotiza con tu pedido.

Características (del fabricante, en inglés)

• Supports Long Range Power Supply Transmission Via Coaxial Cable
• 1*RJ45 10/100Mbps | 1*BNC
• Supports RG59 Coaxial Cable: 400m/100Mbps, 1000m/10Mbps
• Supports MDI/MDIX Self-Adaption
• Supports IEEE802.3, IEEE802.3u Standards
• Sold In Pairs (Transmitter And Receiver)

Medidas y especificaciones (en inglés)

• Network
• Ethernet: 1* 10/100 Mbps Base-TX
• 1* BNC
• Protocol: IEEE802.3, IEEE802.3u
• Electrical
• Power Consumption: <2W
• Environmental
• Operating Conditions: -30°C-65°C
• Operating Humidity: 0%~95%
• Construction
• Dimensions: 79mm × 52mm × 23mm

Descripción del fabricante (en inglés)

IC Realtime's new IVB-EOC-202 is a pair of conversion baluns that adapt existing or newly installed Coax/BNC video cables to carry IP camera feeds and Power over Ethernet (PoE) at distances up to 1000 meters. The EOC-202 is the easiest plug-n-play way to use a PoE-powered IP camera using a standard BNC/coax camera line. Plug one in at the NVR/switch side between the CAT5 and the BNC and use the second unit to convert back to RJ-45 ethernet & PoE connection at the camera end. This pair handles 100Mbs of IP video stream and up to 25 watts of PoE power at 300 feet a 56V DC PoE injector/adapter is used at the NVR end.
